Models

Electric

6SX - Coach Edition

RIB Unlimited 6SX is a revolutionary electric RIB with unprecedented energy efficiency and handling in the 6m RIB segment. The first edition of 6SX is a Coach Edition that has been particularly developed for sailing clubs, harbour operators and other professional users in mind but works well for leisure use too. The electric drivetrain consists of a 50 hp outboard and 25.9 kWh lithium battery from Stream Propulsion which is easily charged from a normal 1-phase 220v power outlet (up to 16A).

    • Electric drivetrain from Stream Propulsion with outboard equivalent to 50hp and 25,9 kWh lithium battery.

    • Battery easily charged from normal 1-phase 220v power outlet (up to 16A).

    • Patented ultralight hydroplane hull for maximal energy efficiency built with vacuum infusion technology.

    • Self-draining ballast tank of 150 litres in foreship for optimal stability in idle speeds and removal of planning hurdle.

    • Large storage and walking areas for optimal accessibility and usability.

    • Tubes in high quality Orca Hypalon with pressure relieve valves in each of the five chambers.

    • Generous standard equipment including touch screen from Stream Propulsion, light grey EVA-floor, self-draining deck, double bow eyes and stainless cleats.

    • Energy consumption only approx. 1 kWh/NM in speeds of around 20 knots with two
      (0,3 kW/NM in speeds of 3-4 knots)

    • Autonomy 20-25 NM in 20 knots (60-75 NM in 3-4 knots).

    • Top speed up to 35 knots.

    • Colour: light grey gelcoat with light grey/grey tubes.

    • LOA 6m / Beam 2.4m / Total weight approx. 670 kg including electric drivetrain.

    • Max load: 6 passengers + 100 kg luggage.

    • Naval architect: Olof Niemer.

Conventional

6S

RIB Unlimited 6S is a revolutionary RIB with unprecedented energy efficiency and handling in the 6m RIB segment. It features a unique and patented ultralight hydroplane hull creating two wet surfaces when in planning mode.

    • CE approved for outboards up to 80hp

    • Fixed fuel tank of 57 liters

    • Patented ultralight hydroplane hull for maximal energy efficiency built with vacuum infusion technology.

    • Self-draining ballast tank of 150 litres in foreship for optimal stability in idle speeds and removal of planning hurdle.

    • Large storage and walking areas for optimal accessibility and usability.

    • Tubes in high quality Orca Hypalon with pressure relieve valves in each of the five chambers.

    • Generous standard equipment including light grey EVA-floor, self-draining deck, double bow eyes and stainless cleats.

    • Fuel consumption below 0,4 liters/NM in speeds of 20-25 knots with a 60hp outboard

    • Top speed with 60hp ouboard of 35+ knots

    • Colour: light grey gelcoat with light grey/grey tubes.

    • LOA 6m / Beam 2.4m

    • Total weight approx. 480kg including 60hp outboard

    • Max load: 6 passengers + 100 kg luggage.

    • Naval architect: Olof Niemer.

8HX

RIB Unlimited 8HX is an impressive 8m RIB with twin electric drivetrains from Stream Propulsion setting a new standard for high speed electric RIBs in the 8m segment. It features an ultralight construction and a hull with dual hydrosteps for optimal energy efficiency. The unique hull design has it’s origin in the boat racing world where it has achieved great success in e.g. the X-3 Offshore race class.

    • Twin electric drivetrain from Stream Propulsion with outboards equivalent to 2x50hp and 2x25,9 kWh lithium batteries.

    • Batteries easily charged from normal 1-phase 220v power outlets (up to 16A).

    • Unique ultralight dual hydrostep hull for maximal energy efficiency built with vacuum infusion technology.

    • Large storage and walking areas for optimal accessibility and usability.

    • Tubes in high quality Orca Hypalon with pressure relieve valves in each of the five chambers.

    • Generous standard equipment including dual touch screen from Stream Propulsion, light grey EVA-floor, self-draining deck and stainless cleats.

    • Energy consumption only approx. 2 kWh/NM in speeds of around 25 knots (0,6 kW/NM in speeds of 3-4 knots)

    • Autonomy up to 25 NM in 25 knots (up to 75 NM in 3-4 knots).

    • Top speed up to 35 knots.

    • Colour: light grey gelcoat with light grey/grey tubes.

    • LOA 7.98m / Beam 2.58m

    • Total weight includin twin electric drivetrains approx. 1100kg.

    • Max load: 8 passengers + 100 kg luggage.

    • Naval architects: Mikael Lundblad and Olof Niemer.

8H

RIB Unlimited 8HX is an impressive 8m RIB featuring an ultralight construction and a hull with dual hydrosteps setting a new standard for energy efficiency in the 8m RIB segment. The unique hull design has it’s origin in the boat racing world where it has achieved great success in e.g. the X-3 Offshore race class.

    • CE approved for outboards up to 150hp

    • Fixed fuel tank of 86 liters

    • Unique ultralight dual hydrostep hull for maximal energy efficiency built with vacuum infusion technology.

    • Large storage and walking areas for optimal accessibility and usability.

    • Tubes in high quality Orca Hypalon with pressure relieve valves in each of the five chambers.

    • Generous standard equipment including light grey EVA-floor, self-draining deck and stainless cleats.

    • Fuel consumption as low as 0.5-0.7 liters/NM in cruising speeds of 25-40 knots with a 115hp outboard

    • Top speed with 115hp outboard up to 50 knots

    • Colour: light grey gelcoat with light grey/grey tubes.

    • LOA 7.98m / Beam 2.58m

    • Total weight incl 115hp outboard approx. 700 kg.

    • Max load: 10 passengers + 100 kg luggage.

    • Naval architects: Mikael Lundblad and Olof Niemer.
